Environmental Sensor Modules
- World’s Smallest Particle, VOC and Barometer Sensors

DataSheets: Download

MicroJet Technology has designed a series of Pump-driven Environmental Air Pollution Sensor Monitor Modules with its world-leading patented technology. By leveraging our CurieJet® customized Air Pump “core module“, MicroJet Technology has developed a series of Air Monitor Modules with extremely small size and can even be integrated into Smart Watch or Mobile Phone for air quality monitoring. Air Pump is very important to circulate air actively in time and drive air sensor to respond quickly. We inhale more than 10,000 liters of air per day. The very air we breathe is growing dangerously polluted, nine out of ten people now breathe polluted air, which kills 7 million people every year. That explains why personal air monitoring in time are important. Click here for reference

Air pollutions are mainly in Particulate matters(PM)and Gaseous pollutants forms. Particulate matters(PM) air pollution may be measured in PM2.5, PM10 and even PM1.0 level fine particulate matters and dust. Gaseous pollutants air pollution may be measured in VOCs(Volatile Organic Compounds) volatile harmful gas, formaldehyde (HCHO/ CH2O) or other cancer-causing material.

P700

P700 Particle Sensor Module uses laser light with Mie scattering theory to measure PM2.5, PM10 and even PM1.0 particulate matter and dust in the air. It adopts our customized air pump, air chamber and MCU and is the world’s smallest optical laser PM 2.5 sensor with size only 29 x 29 x 4.9 mm. It is the smallest size in the world with only 1/4 volume of other optical laser PM2.5 sensors.

P750

P750 Particle & Gas Sensor, with size only 29x 29x 4.9 mm, is the world’s smallest all-in-one air sensor with only 1/16 volume compared with others. P750 uses laser light with Mie scattering theory to measure PM2.5, PM10 and even PM1.0. P750 also integrates BME680 Environmental Sensor that can detect VOC gas, show the ventilation status, sense barometric pressure for weather glass or altitude difference. It also detects ethanol and may be developed as alcohol breath tester, or drunk driving prevention alarm system.

Particulate matters(PM) air pollution may be measured in PM2.5, PM10 and even PM1.0 level fine particulate matters and dust. The newly ISO 16890 Global Air Filtration Standard classifications are based on where particles are deposited in the human lung. PM1 are extremely fine particles and a major subset of PM2.5 that are likely to reach deeper into the body than PM2.5 making them even more harmful as they can reach other organs through the bloodstream. There are more evidences show that COVID-19 coronavirus also spreads through aerosols. PM1 also possible cause for poor visibility. Now, it becomes mandatory for air quality monitors and air purifiers adopt PM1 as measuring parameters, not only PM2.5 & PM10.
( PM1 matters more than PM2.5 )

CurieJet® P750 can detect Volatile Organic Compounds (VOC) from paints (such as formaldehyde), lacquers, paint strippers, cleaning supplies, furnishings, office equipment, glues, adhesives and alcohol. The IAQ (Index for Air Quality)index, valued from 0 to 500, can be deemed as VOC Index to reflect different gaseous pollutants risks of TVOC Level.

Upon request, breath-VOC (b-VOC) which represents the most important compounds in an exhaled breath of humans, can also be supplied as VOC value in ppm.

View PDF Datasheets

The major path of viral infection is by human’s exhaled breath. To reduce the risk of COVID-19 infection, it is important to keep the indoor concentration of exhaled breath as low as possible.
CurieJet® P750 which integrates BME680 sensor detects exhaled human breath and outputs an index of air quality(IAQ). The IAQ (Index for Air Quality)index shows the ventilation status. When IAQ is smaller than 100, there is no ventilation needed.When IAQ is 100-200, it may consider ventilation. When IAQ > 200, it shall ventilate.
https://www.bosch-sensortec.com/news/how-sensing-solutions-help-to-fight-against-covid-19.html

Upon request, eCO2 (CO2 equivalents) that are derived from the average correlation between VOCs and CO2 in human’s exhaled breath, can also be supplied as another ventilation indicator. Please note that eCO2 (CO2 equivalents) in ppm is not CO2 value.

CurieJet® P750 is a highly integrated environmental sensor module. It also senses atmospheric barometric air pressure for weather glass, altitude difference, GPS navigation 3D positioning correction, etc.

In the driving system, it can calculate the altitude difference to provide information on the slope, climbing height, uphill height and downhill height of the vehicle. The air pressure sensor information can correct the GPS navigation device to make 3D positioning more accurate. For example, it can correct the error caused by the GPS in the viaduct because it cannot determine whether the vehicle is on the bridge or under the bridge.

CurieJet® P750, due to built-in BME680 Sensor that detect ethanol, may also be developed as alcohol breath tester, or drunk driving prevention alarm system. Even, it may be applied for The Driver Alcohol Detection System for Safety (DADSS) Program that can passively detect when a driver is under the influence of alcohol and prevent a vehicle from operating.

Evaluation Kit

The P7X0 Evaluation Kit is an evaluation kit for the P700 or P750 modules. It’s an EVB board that helps customers to use the I2C interface easily and apply it easily. It includes an EVB board, adapter board, enternal power supply and jumper link.

DataSheets: Download

Features

  • World’s Smallest & Slimmest Particle, VOC and Barometer Sensors
  • Unique patented technology with built-in air pump
  • Low-power Consumption
  • Long life
  • Silence
  • Excellent Electro-Magnetic Susceptibility
  • Water-proof and Dust-proof (for G200GAS SENSOR MODULE)

Benefits

(Application 1) USB-powered Air Quality Monitor

CurieJet® Sensors, with extremely miniature size, can be designed as separable USB-powered Dongle consumable parts on air purifiers or HVAC machines. While USB-powered air monitors are end of life, the consumable parts are easily swapped by users and don’t need to repair the whole machines.

(Application 2) Wearable Air Quality Monitor

CurieJet® Sensors, with small and slim size, also very low power consumption, developers are flexible to design from fixed, desktop, portable to wearable air quality monitor and various Indoor/Outdoor AIOT air detector devices.

(Application 3) Smart Air Purifying Air Quality Monitor

Using CurieJet® Sensors to design in the remote control air quality monitor, it can work with multiple air purifiers, air conditioners and HVAC ventilation systems for cost-saving and easy installation. While air quality monitors are end of life, the parts are easily repaired or newly purchased and don’t need to repair the whole air purifiers or HVAC machines.

(Application 4) In-Car Air Pollution Control

When the external circulation mode of the car air conditioner is turned on to improve the ventilation, CurieJet® Sensor can verify whether the car air-conditioning filter need to be updated, or need to install a car air purifier to achieve the extremely clean air quality.

Air Sensing Applications

  • Personal Wearable or Mobile PM2.5/PM10/IAQ/TVOC/VOCs/eCO2/CO2 Air Quality Monitors/ Gas Detector/AirBox, may integrate GPS, NB-IOT and other AIOT functions.
  • Air Monitor Adapter/USB Dongle external powered by any USB power source of Mobile Phone, Pad, Notebook, Power Bank, Car USB Power Outlet, etc.
  • Mobile Phone, Phone Case, Tablet PC or Notebook built-in Air Monitor modules.
  • SmartWatch, Smart WristBand, Fitness Tracker, GPS Tracker, etc. built-in Air Monitor modules
  • Wearable Devices such as Smart FaceMask, Smart Clothing, Smart Textile, Smart Belt, Smart Necklace, Brooch, Bag Clip, Bracelet, etc. with Mobile Phone APP
  • Portable Devices such as Mobile PowerBank, Bluetooth Speaker, Smart Speaker, etc.
  • Baby Monitors & Baby Carriages Air Quality Monitoring
  • Personal /Car Air Purifiers built-in air monitor modules
  • Smart Remote Controls built-in P750 air monitor modules for intelligent Air Purifiers, Air Conditioners & HVAC Ventilation System
  • Personal Negative Ion Generator, Wearable Air Purifier built-in air monitor modules
  • Electronic Nose, e-Nose, Oder Meter, Gas Analyzer, Breathalyzer, Breath Alcohol Tester
  • Temperature & Humility Meters, Thermometer, Particle Counter, etc.
  • Smart IOT, Smart City, Smart Building and Smart Factory such as Public Air Quality Monitor, Intelligent Street Lamp, Security & Surveillance Camera Monitor, HVAC(Heating, Ventilation and Air Conditioning) etc.
  • Digital Barometer with air monitoring
  • Aerial Drone Air Quality Monitoring & Altitude measuring
  • Air purification robot, Vacuum cleaner dust sensor

ADDWII® APP

ADDWII APP is available under licensing to support various functions. ADDWII APP support Air Quality Status, Histogram, Camera Shot, Air Map, Personal Trail, Knowledge Info, Account, etc. and create BIG DATA via AI in CLOUD to make the end products become IOT and AIOT devices.

P700
P750

About us

CurieJet® is the marketing brand of Microjet Technology’s Piezoelectric Micro Fluidics products. We have applied for more than 1,600 patents worldwide on micropumps & related products. Most are invention patents. CurieJet Website
